Ubiquiti PoE Injector 24V 30W Gbit
Ubiquiti PoE Adapters provide a variety of features to help protect your PoE devices
Ubiquiti PoE Injector 24V 30W Gbit
Ubiquiti PoE Adapters provide a variety of features to help protect your PoE devices
Лизингов калкулатор
| Характеристика | Стойност |
|---|---|
| Размери PoE | 94 x 60 x 33 mm |
| Output Voltage | 25VDC @ 1.25A |
| Портове PoE | AC Input |
| Гаранция | 24 месеца |
| Арт. номера |
POE-24-30W-G-WH
|
| Specifications | |
|---|---|
| Model | POE-24-30W-G-WH |
| Dimensions | 94 _ 60 _ 33mm (3.70 x 2.36 x 1.30") |
| Weight | 156 g (5.5 oz) |
| Output Voltage | 25VDC @ 1.25A |
| LAN Activity Indicator | No |
| Gigabit LAN Port | Yes |
| Remote Reset Capability | No |
| Reset Button | No |
| Rated Voltage | 100-240VAC @ 50/60Hz |
| Input Current | 0.6A @ 120VAC, 0.4A @ 240VAC |
| Inrush Current | <60A Peak @ 120VAC, <120A Peak @ 230VAC |
| Efficiency | 83+% |
| Output Ripple | 1% Max. |
| Switching Frequency | 65kHz |
| Line Regulation | ≤ 3% |
| Load Regulation | ≤ 5% |
| 2-Pair Powering | Pins 4, 5 (+) and Pins 7, 8 (-) |
| 4-Pair Powering | - |
| Operating Temperature | 0 to 40° C (32 to 104° F) |
| Storage Temperature | -30 to 70° C (-22 to 158° F) |
| Operating Humidity | 35 to 95% Noncondensing |
| AC Connector | IEC-320 C6 |
| Data IN / PoE | RJ45 Shielded Socket |
| Surge Protection | Difference and Common Mode |
| Clamping Protection | 11V Data, 60V Power |
| Max. Surge Discharge | 1500A (8/20 _s) Power |
| Peak Pulse Current | 36A (10/1000 _s) Data |
| Shunt Capacitance | <5 pF data |
| Response Time | <1 ns |
| Certifications | CE, FCC, IC, UL |
