HYTE Y70 Black Cherry
Характеристика | Стойност |
---|---|
Формат | E-ATX |
Поддържани формати |
E-ATX ATX Micro ATX |
Форм фактор | Middle Tower |
Цвят |
Черен Червен |
Включени вентилатори | Няма |
Тегло (Case) | 13.50 кг |
Размери (Case) | 470 x 320 x 470 mm |
Разширителни слотове | 4 + 7 |
Брой вътрешни гнезда | 2 x 3.5” или 4 x 2.5” |
Поддържани вентилатори |
Rear: 1 x 120/140 mm Top: 3 x 120/2 x 140 mm Bottom: 3 x 120/2 x 140 mm Side: 3 x 120/2 x 140 mm |
Макс. височина CPU охладител | 180 mm |
Макс. дължина видео карта | 422 mm |
Други (Case) | Включен: PCIe 4.0 x16 GPU Riser cable |
Съвместимост на Радиатори |
Top: Up to 360/280 mm Side: up to 360/280 mm |
Преден панел I/O Ports |
1 x Audio Combo jack 1 x USB 3.2 Gen 2 Type C 2 x USB 3.2 Gen 1 |
Дължина захранване | до 235 mm |
Гаранция | 24 месеца |
Арт. номера |
HYTE-CASE-GEHY-024
|
Y70 Modern Aesthetic Case
Enhanced In Every Dimension
Y70 is an upgraded dual chamber ATX mid tower modern aesthetic case that delivers next gen gaming experiences with massive 4 slot vertical graphics and unlocks maximum performance via ginormous cooling capacity. All while celebrating your favorite hardware by showing off your PC the way it was meant to be seen.
Massive 4 Slot Vertical Graphics
Y70 grows GPU support to 4 slots with additional airflow space between the edge of the card and the glass. This means you can fit even the largest and most powerful of graphics cards into your build with ease. Additionally, the cold floor cooling down below can house up to a trio of 120mm or duo of 140mm fans up to 32mm thick to direct fresh airflow straight into the GPU.
Included Luxury PCIE 4.0 Riser Cable
Included with the case is a luxury PCIE 4.0 x 16 riser with a color-matched canopy for uninterrupted visual flow that'll make for a painless GPU installation and build process. It also allows for a plethora of half-height PCIE cards to sit behind the throne of the vertical graphics.
Ginormous Cooling Capacity
A spacious interior makes room for up to a 360mm long & 125mm thick radiator on the side and adjustable top bracket that can house another 360mm radiator up to 68mm thick up above. Working together with the cold floor cooling at the bottom and spot for an additional fan at the rear of the case, Y70 has a total capacity of 10 fans in a fully populated chassis. With over 180mm of clearance to the side glass, air and water cooling enthusiasts alike will appreciate the flexibility afforded to them by the chassis to create the most robust cooling configurations possible.
Unified Modern Aesthetic
With 4 unique colorways, Y70 puts your build front and center with a beautifully crafted 3-piece panoramic glass which serves as a window into the heart of your PC. The dual chamber interior layout keeps the front looking great while giving you plenty of space to manage cables in the back, especially with the help of our seamless L-shaped molded rubber grommet, meticulously placed cable routing channels & tie-down points, and reusable Velcro straps. All easily accessible with tool-less top and side panels alongside floating storage sleds that eject from the rear of the case for intuitive drive maintenance.
