ASROCK B450 PRO4 R2.0
ASROCK Main Board Desktop B450 PRO4 (B450, AM4, 4xDDR4, HDMI/DP/D-Sub, 2 PCIe 3.0 x16, 4 PCIe 2.0 x1, 2xM.2, 6 SATA3, 1x USB-C, 2xUSB 2.0, 5x USB 3.2, 1xCOM Port Header, ATX, Retail)
ASROCK B450 PRO4 R2.0
ASROCK Main Board Desktop B450 PRO4 (B450, AM4, 4xDDR4, HDMI/DP/D-Sub, 2 PCIe 3.0 x16, 4 PCIe 2.0 x1, 2xM.2, 6 SATA3, 1x USB-C, 2xUSB 2.0, 5x USB 3.2, 1xCOM Port Header, ATX, Retail)
Лизингов калкулатор
| Характеристика | Стойност |
|---|---|
| CPU Socket | AM4 |
| Чипсет | AMD B450 |
| Форм фактор | ATX |
| Слотове памет | 4 |
| Поддържана памет | DDR4 |
| Максимален капацитет RAM памет | 128 GB |
| Честота памет | ECC/Non-ECC |
| Аудио | 7.1 Realtek ALC892/897 Audio Codec |
| LAN |
1Gb Ethernet Realtek RTL8111H chip (10/100/1000 Mbit) |
| Поддържани процесори | AMD Ryzen Series |
| Свързаност |
1 x RJ-45 PS/2 (combo KB/M) |
| Конектор захранване | 1 x 24-pin;1 x 8-pin |
| Слотoве PCI-E x16 | 2 |
| Слотoве PCI-E x1 | 4 |
| Видео портове |
1 x DisplayPort 1 x HDMI 1 x VGA |
| USB портове |
4 (USB 3.2 (type A)) 2 (USB 2.0 (type A)) 1 (USB 3.2 (type A)); 1 (USB 3.2 (type C)) |
| Гаранция | 36 месеца |
| Арт. номера |
B450 PRO4 R2.0
64687
ASR-MB-B450-PRO4-R2
|
B450 Pro4 R2.0
- Supports AMD AM4 Socket Ryzen™ 2000, 3000, 4000 G-Series, 5000 and 5000 G-Series Desktop Processors
- Supports DDR4 3200+ (OC)
- 2 PCIe 3.0 x16, 4 PCIe 2.0 x1
- AMD Quad CrossFireX™
- Graphics Output: HDMI, Display Port, D-Sub
- 7.1 CH HD Audio (Realtek ALC892/897 Audio Codec)
- 6 SATA3, 1 Ultra M.2 (PCIe Gen3 x4), 1 M.2 (PCIe Gen3 x2 & SATA3)
- 2 USB 3.2 Gen2 (Rear Type A+C)
- 6 USB 3.2 Gen1 (2 Front, 4 Rear)
- Realtek Gigabit LAN
